Products.

We offer a wide range of products for marine applications which exploit our knowledge in rubber, steel, polyurethane and polyethylene. You can expect high-quality products at competitive prices.

Text 1
Text 1
Pneumatic Fender Dimensions + Performance Values
  Initial Pressure 0.5
kg / cm²
      Initial Pressure 0.8
kg / cm²
    Weight
Fender
Size
[mm]
Energy
[kNm]
Reaction
[kN]
Pressure
[kN/m²]
Energy
[kNm]
Reaction
[kN]
Pressure
[kN/m]
Body
[kg]
Chain net
[kg]
Total
[kg]
300x500 1,3 22,6 189 1,7 29,4 246 10 n / a 10
300x600 1,5 26,5 180 2 35,3 239 15 n / a 15
500x800 5,7 58,9 187 7,4 78,5 249 25 n / a 25
500x1000 7,2 73,6 179 9,1 98,1 239 35 n / a 35
800x1200 21,6 141 188 28,1 187 250 75 100 175
800x1500 27,5 186 191 35,1 235 241 95 110 205
1000x1500 40,2 222 190 52,7 281 240 140 170 310
1000x2000 54 295 180 70,2 374 228 170 200 370
1200x1800 69,7 320 190 91 404 240 180 210 390
1200x2000 77,5 354 185 101 449 235 200 220 420
1350x2500 125 496 181 175 650 238 270 260 530
1500x2500 152 554 186 196 697 234 300 400 700
1500x3000 182 658 178 235 837 227 350 440 790
2000x3000 324 883 189 422 1,122 240 550 880 1,430
2000x3500 378 1,030 183 491 1,315 234 650 920 1,570
2000x6000 647 1,766 171 843 2,246 217 950 1,120 2,170
2500x4000 675 1,481 188 872 1,864 236 1,100 1,510 2,610
2500x5500 928 2,037 178 1,197 2,560 224 1,350 1,620 2,970
3000x5000 1,126 2,207 185 1,570 2,786 233 1,700 2,620 4,320
3300x4500 1,324 2,197 194 1,712 2,764 244 1,800 2,360 4,160
3300x6500 1,913 3,169 181 2,472 3,993 228 2,250 3,120 5,370
3300x10500 3,090 5,121 171 4,297 6,612 220 2,800 4,050 6,850
4500x7000 3,816 4,660 186 4,944 5,866 234 3,250 5,100 8,350
4500x9000 4,954 6,004 152 6,357 7,544 191 4,950 6,200 11,150
